With the MEW4 buggy, we are seamlessly continuing our successful vehicle series in 1:16 scale. Thanks to its technically high-quality equipment, the model is unparalleled in this class: A brushless motor, metal drive train, CVD drive shafts, oil-pressure shock absorbers and metal differentials are just some of the features that raise the MEW4 to a remarkable level. The large Li-Ion battery with 1500mAh ensures long driving times of up to 15 minutes. The achievable speed is around 40km/h. A 35A ESC and a 17g steering servo as well as inactive cooling (cooling fins) for the motor also contribute to the high durability.
The chassis as well as the wishbones and shock towers are made of composite plastic. An adjustable chassis and the aluminium oil-pressure shock absorbers ensure direct handling – full control at full speed lends. The Race Buggy is splash-proof and has ball bearings. This means that the model is fully suitable for outdoor use and cuts a fine figure on any surface. For efficient power transmission of the strong drive to all four wheels (4WD), the vehicle was additionally equipped with a main gear wheel and a motor pinion made of metal. A 2.4 GHz remote control that fits well in the hand is also included with the RTR set.
Highlights:
All drive parts made of metal: For a high durability of the components
Aluminium oil-pressure shock absorbers: For best control on any surface
Powerful 2835 brushless drive: For more power and acceleration in any terrain
Other features:
Adjustable chassis
Composite plastic parts for durability even under heavy loads
Large Li-Ion battery with 1500mAh for long driving times of up to 15 minutes included
Charging cable with balancer connection included
Bright and switchable LED lighting at the front for riding at dusk and dawn
CVD drive shafts for loss-free drive to the wheels and long-lasting durability
Ball bearing drive for direct and safe propulsion
Powerful steering servo for maximum control while driving
Large 35A ESC fitted
Speed pre-selectable via transmitter (75/100%)
Technical data:
Scale: 1:16
Length: 265mm
Width: 205mm
Height: 95mm
Weight: 880g
Wheelbase: 175mm
Track width front: 175mm
Track width rear: 175mm
Ground clearance: 22mm
Front wheels: Outer diameter/width 72/30mm
Rear wheels: Outer diameter/width 72/30mm
Rim diameter: 55mm
Gearbox: Metal
Front shock absorber: Length 60mm
Rear damper: Length 65mm
Brake: Electronic
ESC: Brushless 35A ESC
Motor: Brushless 2835
Drive system: Cardan
Steering servo: 17g Midi
Main material: Plastic
Battery compartment dimensions: 78x38x30mm
Battery: Li-Ion 2S 7,4V 1500mAh Hardcase, Deans connector (T-Plug), 78x38x20mm, 105g
Driving time: approx. 15min, depending on driving style and surface
Top speed: approx. 40km/h
Remote control: 2,4GHz, 3-channel
Range: approx. 60-80m
Charger: USB, balancer connection
Charging time: approx. 120-150min
Scope of delivery:
Model
Remote control
Charging cable
Various accessories
Manual DE/EN
Required accessories:
2x 1.5V Mignon AA batteries for remote control
